High -Speed Three-Layer Rotary Tabletting Machine |
MODEL |
JC-TH-39DB |
| Max. diameter |
19mm (Caplet) |
| Hourly output double -layer |
60,000 |
| Hourly output three -layer |
52,000 |
| Max. pre-pressure (I) |
30,000 kgs |
| Max. pre-pressure (II) |
30,000 kgs |
| Max. operation pressure |
10,000 kgs |
|
|
| ................................................................................................................................... |
|
High-Speed Multi-Layar Rotary Tabletting Machine
(Tabletting Compartment Separated Form Drive Mechanism)
|
Single Layer Double-Sided Tabletting Device
MODEL |
JC-DH-23S |
JC-DH-29S |
JC-DH-35S |
| Max. diameter |
20mm |
19mm (Caplet) |
13mm |
| Hourly output |
135,000 |
167,000 |
200,000 |
| Max. pressure |
10,000 kgs |
|
Double Layer Single-Sided Tabletting Device
MODEL |
JC-DH-23D |
JC-DH-29D |
JC-DH-35D |
| Max. diameter |
20mm |
19mm (Caplet) |
13mm |
| Hourly output |
42,000 |
52,000 |
58,000 |
| Max. pressure |
10,000 kgs |
|
|
| ................................................................................................................................... |
|
High- Speed Rotary Tabletting Machine |
Double Pressure System
MODEL |
JC-RT-16H |
JC-RT-20H(DB) |
| Max. diameter |
25.4mm |
19mm (Caplet) |
| Hourly output |
69,000 |
86,000 |
| Max. pre -pressure |
30,000 kgs |
| Max. operation -pressure |
10,000 kgs |
|
MODEL |
JC-RT-24H |
JC-RT-20H(B) |
| Max. diameter |
13mm |
16mm |
| Hourly output |
103,000 |
86,000 |
| Max. pre -pressure |
30,000 kgs |
| Max. operation -pressure |
6,000 kgs |
|
|
|
High-Speed Single-Sided Rotary Tabletting Machine |
Double Pressure System
MODEL |
JC-RT-310D |
JC-RT-39DB |
| Max. diameter |
25.4mm |
19mm (Caplet) |
| Hourly output |
111,600 |
140,000 |
| Max. pre -pressure |
10,000 kgs |
| Max. operation -pressure |
10,000 kgs |
|
MODEL |
JC-RT-47BB |
JC-RT-39B |
| Max. diameter |
13mm |
16mm |
| Hourly output |
169,000 |
140,000 |
| Max. pre -pressure |
6,000 kgs |
| Max. operation -pressure |
6,000 kgs |
|
High-Speed Single-Sided Rotary Tabletting Machine |
Double Pressure System
MODEL |
JC-SSH-23D |
JC-SSH-29DB |
| Max. diameter |
25.4mm |
19mm (Caplet) |
| Hourly output |
28,800 |
105,000 |
| Max. pre -pressure |
10,000 kgs |
| Max. operation -pressure |
10,000 kgs |
|
MODEL |
JC-SSH-35BB |
JC-SSH-39B |
| Max. diameter |
13mm |
16mm |
| Hourly output |
126,000 |
105,000 |
| Max. pre -pressure |
6,000 kgs |
| Max. operation -pressure |
6,000 kgs |
|
|
| .................................................................................................................................. |
|
High-Speed Double-Sided Rotary Tabletting Machine
(Tabletting Compartment Separated Form Drive Mechanism)
|
Double Pressure System
MODEL |
JC-DSH-31D |
JC-DSH-39DB |
| Max. diameter |
25.4mm |
19mm (Caplet) |
| Hourly output |
200,000 |
260,000 |
| Max. pre -pressure |
3,000 kgs |
| Max. operation -pressure |
10,000 kgs |
|
MODEL |
JC-DSH-35BB |
JC-DSH-39B |
| Max. diameter |
16mm |
13mm |
| Hourly output |
260,000 |
312,000 |
| Max. pre -pressure |
3,000 kgs |
| Max. operation -pressure |
6,000 kgs |
|
|
| .................................................................................................................................. |
* Punch & Die Department exists for one purpose only to supply customers with.
* optimum quality produced on time to exact design requirement at a highly competitive price. |
|
* The manufacturer reserves the right to modify the design, specification, etc., to improve the performance of the machine without notice.
* All the specification shown are just for reference. |
|
*Subjest to the characteristics of the power.
*The manufacturer reserves the right to modifty the design, specifiaction, etc., to improve
the performance of the machine without notice. All the specifiaction shown are reference only. |
|
|
| |
|
| |
|
|
|
|
